Ford Mustang Service Manual: Window Glass - Door

Glass, Frames and Mechanisms (Description and Operation)

Component Location






Windshield Glass


Windshield Glass

The windshield exterior mouldings are installed with the windshield glass. The windshield exterior mouldings cannot be replaced without removal of the windshield.

Window Regulator Control Switch

Power windows are standard on all models. On coupe models, only the front door window glass can be raised or lowered. The quarter window glass is fixed. On the convertible models, all four windows can be raised or lowered. On all models, the window regulator control switches are available only to the front seat passengers. There are no window regulator controls for the back seat passengers.

Quarter window glass operations are controlled by the driver window regulator control switch.

Window, One-Touch Down

The LH window one-touch down feature is activated by momentarily pressing the driver window regulator control switch to the down position. This allows the front door window glass to move downward until it is fully lowered. Momentarily pressing the window regulator control switch while the window glass is moving downward will stop the front door window glass.

Window Glass, Door

The bottom of the door window glass is mounted on a slider bracket which is part of the front door window regulator. Door window glass bracket spacers provide attachment points for the door window glass and prevent direct contact between the slider bracket and the door window glass.

Window Glass, Quarter

The rear quarter window glasses on convertible models are driven by a window regulator motor and guide assembly.

Window Glass, Rear

On the coupe, the rear window upper garnish mouldings are installed with the rear window glass. The rear window upper garnish mouldings cannot be replaced without removing the rear window glass.

    Installation
    Removal Convertible 1. For removal of the back window glass, refer to Section. Coupe WARNING: To prevent glass splinters from entering eyes or cutting hands, wear safety glasses and heavy ...

    Window Glass - Quarter
    Glass, Frames and Mechanisms (Description and Operation) Component Location   Windshield Glass The windshield exterior mouldings are installed with the windshield glass. The windshield ext ...
