Ford Mustang Service Manual: Transmission Support Crossmember

Transmission Description (Description and Operation)

The 4R70W has the following features:

  • Wide ratio gears
  • Four speeds
  • Rear wheel drive
  • Automatic
  • Electronic shift
  • Torque converter clutch control
  • Line pressure controls

The transmission uses Ravigneaux-style double-pinion gearset with two bands, one one-way roller clutch, one mechanical diode and four friction clutches to produce four forward gears and Reverse.

4R70W Automatic Transmission
